Operationsmikroskope für die Augenheilkunde
Operationsmikroskope
Ophthalmologische Operationsmikroskope von Haag-Streit zeichnen sich durch eine herausragende Optik und Ergonomie aus. Mikroskope von Haag-Streit verfügen über hochpräzise Optiken made in Switzerland und sind bekannt für ihre hochauflösende Visualisierung und verbesserte Tiefenschärfe. Eine gut durchdachte Ergonomie unterstützt Augenchirurgen zusätzlich dabei, ihr Bestes zu geben.
Vergleiche unsere Produkte
| Hi-R NEO 900 Microscope | METIS 900 | |
|---|---|---|
| Zubehör (Auswahl) | ||
| Microscope rotation (°) | 540 | 540 |
| Controls | ||
| Integrated status display | ● | ● |
| Graphical user interface for user specific presets and controls | ● | ● |
| Foot switch with up to 14 functions | ● | ● |
| Electromagnetic brakes for microscope and floor stand | ● | ● |
| Hand switch button programmable | − | ● |
| Dimensions | ||
| Floor stand carriage (mm / inch) | 732 x 727 mm / 28.82 x 28.62 inches | 789 x 880 mm / 31.06 x 34.64 inches |
| Arm reach, max. (mm / inch) | 1320 mm / 51.97 inches | 1320 mm / 51.97 inches |
| Height at oculars (mm / inch) | 1063 to 1783 mm / 41.85 to 70.2 inches | (1072 - 1802 mm (delta > 730 mm) / 42.2 - 70.94 (delta > 28.74mm) inches |
| Min. door height (mm / inch) | 1939 mm / 76.34 inches | 1891 mm / 74.45 inches |
| Microscope weight, without accessories (kg / lbs) | 9.2 kg / 20.28 lbs | 9.2 kg / 20.28 lbs |
| Floor stand weight (kg / lbs) | 230 kg / 507 lbs | 315 kg / 695 lbs |
| Focal length | ||
| Focal length 200mm / 7.87 in | ● | ● |
| Focal length 175mm / 6.89 in | ○ | ● |
| Illumination | ||
| LED illumination | ● | ● |
| Protection filter: UV, IR | ● | ● |
| Slit illumination | ● | ● |
| Filters: UV, soft light, daylight, blue | ● | ● |
| Slit and spot illumination | ● | ● |
| Retina protection filter [nm] | ● | ● |
| Filters: blue light, soft light | ● | ● |
| Movement ranges | ||
| Floor stand arms swivel (deg.) 2x 270° | ● | ● |
| X-Y coupling movement (mm / inch) 60 x 60 mm / 2.36 x 2.36 inches | ● | ● |
| Microscope inclination (deg.) | -70 to +90 | -20 to +110 (motorized) |
| Visualization | ||
| Red reflex enhancer | ● | − |
| Stereo base: 25mm / 0.98 in | ● | ● |
| Optics with apochromatic properties | ● | ● |
| Motorized zoom with 1:6 ratio | ● | ● |
| Motorized focus, range: 50mm / 1.97 in | ● | ● |
| Integrated depth of field | − | ● |
| Microscope | ||
| Inclined eyepiece | ● | ● |
● standard | ○ optional | − not available | □ not recomended
