Leader depuis 1933
Lampes à fente
Les lampes à fente Haag-Streit sont réputées pour leurs performances et leur longévité. Depuis plus de 90 ans, notre souci du détail et notre engagement à produire les meilleures lampes à fente vous mettent en confiance.
Comparer nos produits
Elara 900 | BQ 900 | BP 900 | BI 900 | BM 900 | BX 900 | |
---|---|---|---|---|---|---|
Microscope | ||||||
Galilean microscope | ● | ● | ● | − | − | ● |
Kepler microscope | − | − | − | ● | ● | − |
Stereo angle 13° | ● | ● | ● | ● | ● | ● |
Stereo variator (stereo angle 4.5°) | − | ○ | − | − | − | □ |
Inclined eyepiece | ● | ○ | − | − | − | ○ |
Yellow filter | ● | ○ | ○ | ● | − | ○ |
Second observer tube | − | ○ | − | − | − | □ |
Beam splitter | ● | ○ | − | − | − | □ |
Magnification (Std. Eyepieces) | ||||||
6.3 × | ● | ● | − | − | − | ● |
10 × | ● | ● | ● | ● | ● | ● |
16 × | ● | ● | ● | ● | ● | ● |
25 × | ● | ● | ● | − | − | ● |
40 × | ● | ● | − | − | − | ● |
Illumination | ||||||
LED | − | ● | ● | ● | ● | ● |
RGB-LED (P-Type) | ● | − | − | − | − | − |
Presets | ● | − | − | − | − | − |
Infrared (Availability may vary by region) | ● | − | − | − | − | − |
Background | ● | ○ | ○ | ○ | − | ● |
Tilt | − | ● | ● | ● | ● | ● |
Defocusing | − | ● | ● | ● | ● | ● |
Short illumination mirror | − | ○ | ○ | ○ | ○ | ○ |
Filter | ||||||
Gray | ● | ● | ● | ● | ● | ● |
Red-free | ● | ● | ● | ● | ● | ● |
Blue | ● | ● | ● | ● | ● | ● |
Slit | ||||||
Width (continuous) (mm / inch) | 0 - 25 mm / 0 - 0.98 inches | 0 - 14 mm / 0 - 0.55 inches | 0 - 14 mm / 0 - 0.55 inches | 0 - 14 mm / 0 - 0.55 inches | 0 - 8 mm / 0 - 0.315 inches | 0 - 8 mm / 0 - 0.315 inches |
Length (continuous) (mm / inch) | 0 - 14 mm / 0 - 0.55 inches | 1 - 14 mm / 0.394 - 0.55 inches | 1 - 14 mm / 0.394 - 0.55 inches | 1 - 14 mm / 0.394 - 0.55 inches | 1 - 8 mm / 0.039 - 0.315 inches | 1 - 8 mm / 0.039 - 0.315 inches |
Test mark fixation star | − | ● | ● | ● | ● | ● |
Imaging | ||||||
Integrated imaging (Stereo optional) | ● | − | − | − | − | − |
IM 910 | − | ○ | − | − | − | − |
IM 600 | − | ○ | ○ | − | − | − |
Imaging Set BI 900 | − | − | − | ○ | − | − |
DSLR camera connector | − | − | − | − | − | ● |
Integrated flash (slit and background) | − | − | − | − | − | ● |
Control elements | ||||||
Mechanical | ● | ● | ● | ● | ● | ● |
Color touch display | ● | − | − | − | − | − |
Tonometry | ||||||
AT 900 mod. BQ | − | ○ | ○ | − | − | □ |
AT 900 mod. R | ○ | − | − | ○ | ○ | − |
AT 900 mod. T | − | ○ | ○ | ○ | ○ | − |
Dimensions | ||||||
Weight (kg / lbs) | 15.2 kg / 33.51 lbs | 12.7 kg / 20.28 lbs | 12.3 kg / 27.11 lbs | 12 kg / 26.45 lbs | 11.4 kg / 25.13 lbs | 14.8 kg / 32.63 lbs |
Dimensions L x W x H (mm / inch) | 560 mm × 401 mm × 330 mm / 22 x 15.8 x 13 inches | 305 x 332 x 700 mm / 12 x 13 x 27.56 inches | 305 x 332 x 700 mm/ 12 x 13 x 27.56 inches | 310 x 332 x 700 mm / 12.2 x 13 x 27.56 inches | 290 x 332 xx 700 mm / 11.42 x 13 x 27.56 inches | 370 x 332 x 800 mm / 14.57 x 13 x 31.5 inches |
● standard | ○ optional | − not available | □ not recommended
